Mogami W2534 2534 Microphone Wire 24ga Gold Mic Wire, Per Foot
Mogami 2534 W2534 Cable by-the-foot
Sold here by the foot, order what you need.
Neglex Quad Gold Microphone Cables
Mogami Neglex Gold quad cable is perfect cable for home studios suffering from wiring and grounding problems. Mogami 2534 should also be used where intense RFI interference is a problem. Mogami 2534 provides an improvement in signal to noise of 10-20db over equivalent twisted pair cables. Double conductors quad cables are more effective in cancelling noise that can get past even the best of shields and is critical in an environment of high RF and EM interference.
Conductor insulation is XLPE ( Cross-Linked Polyethylene) which has excellent electrical characteristics and prevents shrink-back during soldering.
Served (spiral) Bare Copper Shield is superior to foil or braided shields for sound quality and simplifies termination.
Part No. W2534
No. of Conductor 4(Quad)
Conductor Details 20/0.12 OFC
Size(mm²) 0.226mm² (#24 AWG)
Insulation Ov. Dia.(mm) 1.6Ø (0.063″)
Material XLCPE (Cross-Linked Polyethylene)
Color Blue / Clear (Quad) Black
Served Shield Approx. 64/0.18A
Jacket Ov. Dia.(mm) 6.0Ø (0.236″)
Material Flexible PVC
Reference Standard NEGLEX Quad High Definition Microphone Cable
NEGLEX No. W2534 has become popular around the world as the standard for high quality digital and analog recording. The cable has also become popular for use with unbalanced equipment, such as high quality pre-amp, amp inputs and tape decks. Miniature Quad Superflexible Microphone Cable Originally designed for BANTAM patch-cords, this cable has become popular where a small diameter Quad mic cable is required.
